Installing FreeRADIUS

  1. Head over to the FreeRADIUS site,, and download the latest release.
       # cd /usr/local/src
       # wget
       # tar zxfv freeradius-1.0.0.tar.gz
       # cd freeradius-1.0.0
  2. Configure, make and install:
        # ./configure
        # make
        # make install

    You can pass options to configure. Use ./configure –help or read the README file, for more information.

The binaries are installed in /usr/local/bin and /usr/local/sbin. The configuration files are found under /usr/local/etc/raddb.

If something went wrong, check the INSTALL and README included with the source. The RADIUS FAQ also contains valuable information.

3.2. Configuring FreeRADIUS

FreeRADIUS has a big and mighty configuration file. It’s so big, it has been split into several smaller files that are just “included” into the main radius.conf file.

There is numerous ways of using and setting up FreeRADIUS to do what you want: i.e., fetch user information from LDAP, SQL, PDC, Kerberos, etc. In this document, user information from a plain text file, users, is used.

Tip The configuration files are thoroughly commented, and, if that is not enough, the doc/ folder that comes with the source contains additional information.

Configuring FreeRADIUS

  1. The configuration files can be found under /usr/local/etc/raddb/
        # cd /usr/local/etc/raddb/
  2. Open the main configuration file radiusd.conf, and read the comments! Inside the encrypted PEAP tunnel, an MS-CHAPv2 authentication mechanism is used.
    1. MPPE [RFC3078] is responsible for sending the PMK to the AP. Make sure the following settings are set:
          # under MODULES, make sure mschap is uncommented!
          mschap {
            # authtype value, if present, will be used
            # to overwrite (or add) Auth-Type during
            # authorization. Normally, should be MS-CHAP
            authtype = MS-CHAP
            # if use_mppe is not set to no, mschap will
            # add MS-CHAP-MPPE-Keys for MS-CHAPv1 and
            # MS-MPPE-Recv-Key/MS-MPPE-Send-Key for MS-CHAPv2
            use_mppe = yes
            # if mppe is enabled, require_encryption makes
            # encryption moderate
            require_encryption = yes
            # require_strong always requires 128 bit key
            # encryption
            require_strong = yes
            authtype = MS-CHAP
            # The module can perform authentication itself, OR
            # use a Windows Domain Controller. See the radius.conf file
            # for how to do this.
    2. Also make sure the “authorize” and “authenticate” contains:
          authorize {
          authenticate {
               #  MSCHAP authentication.
               Auth-Type MS-CHAP {
               #  Allow EAP authentication.
  3. Then, change the clients.conf file to specify what network it’s serving:
       # Here, we specify which network we're serving
       client {
            # This is the shared secret between the Authenticator (the
            # access point) and the Authentication Server (RADIUS).
            secret          = SharedSecret99
            shortname       = testnet
  4. The eap.conf should also be pretty straightforward.
    1. Set “default_eap_type” to “peap”:
            default_eap_type = peap
    2. Since PEAP is using TLS, the TLS section must contain:
          tls {
              # The private key password
              private_key_password = SecretKeyPass77
              # The private key
              private_key_file = ${raddbdir}/certs/cert-srv.pem
              #  Trusted Root CA list
              CA_file = ${raddbdir}/certs/demoCA/cacert.pem
              dh_file = ${raddbdir}/certs/dh
              random_file = /dev/urandom
    3. Find the “peap” section, and make sure it contain the following:
            peap {
              #  The tunneled EAP session needs a default
              #  EAP type, which is separate from the one for
              #  the non-tunneled EAP module.  Inside of the
              #  PEAP tunnel, we recommend using MS-CHAPv2,
              #  as that is the default type supported by
              #  Windows clients.
              default_eap_type = mschapv2
  5. The user information is stored in a plain text file users. A more sophisticated solution to store user information may be preferred (SQL, LDAP, PDC, etc.).Make sure the users file contains the following entry:
       "testuser"      User-Password == "Secret149"
