How to Install JBOSS Network Operation with  PostGreSQL and RHQ Agent

Pre requisites!

  • Kernel Update
  • Host File Setting
  • Centos 6 x86_64
  • Oracle Java JDK 1.6.0_45
  • POSTGRESQL
  • Jon-server_3.2.0

Download ORACLE JAVA Form www.oracle.com jdk-6u45-linux-x64-rpm.bin

Kernal Update.

[root@jonserver.local ~]#yum update -y

Example of Host file.
To make all applications use /etc/hosts exclusively when looking up the IP address of a host, you have to edit the /etc/hosts file.

Hosts File

[root@jonserver.local ~]# vi /etc/hosts
127.0.0.1 localhost localhost.localdomain localhost4 localhost4.localdomain4
::1 localhost localhost.localdomain localhost6 localhost6.localdomain6

192.168.0.200 my.jonserver.local
:wq!

Oracle JAVA Installation

[root@ jonserver.local opt]# chmod 755 jdk-6u45-linux-x64-rpm.bin
[root@ jonserver.local opt]# ./jdk-6u45-linux-x64-rpm.bin
Unpacking…
Check summing…
Extracting…
UnZipSFX 5.50 of 17 February 2002, by Info-ZIP (Zip-Bugs@lists.wku.edu).
inflating: jdk-6u45-linux-amd64.rpm
inflating: sun-javadb-common-10.6.2-1.1.i386.rpm
inflating: sun-javadb-core-10.6.2-1.1.i386.rpm
inflating: sun-javadb-client-10.6.2-1.1.i386.rpm
inflating: sun-javadb-demo-10.6.2-1.1.i386.rpm
inflating: sun-javadb-docs-10.6.2-1.1.i386.rpm
inflating: sun-javadb-javadoc-10.6.2-1.1.i386.rpm
Preparing… ########################################### [100%] 1:jdk ########################################### [100%] Unpacking JAR files…
rt.jar…
jsse.jar…
charsets.jar…
tools.jar…
localedata.jar…
plugin.jar…
javaws.jar…
deploy.jar…
Installing JavaDB
Preparing… ########################################### [100%] 1:sun-javadb-common ########################################### [ 17%] 2:sun-javadb-core ########################################### [ 33%] 3:sun-javadb-client ########################################### [ 50%] 4:sun-javadb-demo ########################################### [ 67%] 5:sun-javadb-docs ########################################### [ 83%] 6:sun-javadb-javadoc ########################################### [100%]

Done.

Set Oracle Java Path

[root@ jonserver.local opt]# ln -s /usr/java/jdk1.6.0_45/bin/java /usr/bin/java

Verify Oracle Java.
[root@ jonserver.local opt]# java -version
java version “1.6.0_45”
Java(TM) SE Runtime Environment (build 1.6.0_45-b06)
Java HotSpot(TM) 64-Bit Server VM (build 20.45-b01, mixed mode)

Export Oracle Java Path into >> /etc/profile

[root@ jonserver.local opt]# echo “export JAVA_HOME=/usr/java/jdk1.6.0_45” >> /etc/profile

Verify /etc/profile

[root@jonserver.local opt]#cat /etc/profile

# /etc/profile

# System wide environment and startup programs, for login setup
# Functions and aliases go in /etc/bashrc

# It’s NOT a good idea to change this file unless you know what you
# are doing. It’s much better to create a custom.sh shell script in
# /etc/profile.d/ to make custom changes to your environment, as this
# will prevent the need for merging in future updates.

pathmunge () {
case “:${PATH}:” in
*:”$1″:*)
;;
*)
if [ “$2” = “after” ] ; then
PATH=$PATH:$1
else
PATH=$1:$PATH
fi
esac
}
if [ -x /usr/bin/id ]; then
if [ -z “$EUID” ]; then
# ksh workaround
EUID=`id -u`
UID=`id -ru`
fi
USER=”`id -un`”
LOGNAME=$USER
MAIL=”/var/spool/mail/$USER”
fi

# Path manipulation
if [ “$EUID” = “0” ]; then
pathmunge /sbin
pathmunge /usr/sbin
pathmunge /usr/local/sbin
else
pathmunge /usr/local/sbin after
pathmunge /usr/sbin after
pathmunge /sbin after
fi

HOSTNAME=`/bin/hostname 2>/dev/null`
HISTSIZE=1000
if [ “$HISTCONTROL” = “ignorespace” ] ; then
export HISTCONTROL=ignoreboth
else
export HISTCONTROL=ignoredups
fi

export PATH USER LOGNAME MAIL HOSTNAME HISTSIZE HISTCONTROL

# By default, we want umask to get set. This sets it for login shell
# Current threshold for system reserved uid/gids is 200
# You could check uidgid reservation validity in
# /usr/share/doc/setup-*/uidgid file
if [ $UID -gt 199 ] && [ “`id -gn`” = “`id -un`” ]; then
umask 002
else
umask 022
fi

for i in /etc/profile.d/*.sh ; do
if [ -r “$i” ]; then
if [ “${-#*i}” != “$-” ]; then
. “$i”
else
. “$i” >/dev/null 2>&1
fi
fi
done
unset i
unset -f pathmunge
export JAVA_HOME=/usr/java/jdk1.6.0_45

[root@ jonserver.local opt]# source /etc/profile.

Verify Oracle Java Path

[root@ jonserver.local opt]# echo $JAVA_HOME
/usr/java/jdk1.6.0_45

PostgreSQL Installation

[root@ jonserver.local opt]# yum install postgresql*
Loaded plugins: fastestmirror
Loading mirror speeds from cached hostfile
* base: stingray.cyber.net.pk
* extras: stingray.cyber.net.pk
* updates: stingray.cyber.net.pk
Setting up Install Process
Resolving Dependencies
–> Running transaction check
—> Package postgresql.x86_64 0:8.4.18-1.el6_4 will be updated
—> Package postgresql.x86_64 0:8.4.20-1.el6_5 will be an update
—> Package postgresql-contrib.x86_64 0:8.4.20-1.el6_5 will be installed
–> Processing Dependency: libossp-uuid.so.16()(64bit) for package: postgresql-contrib-8.4.20-1.el6_5.x86_64
—> Package postgresql-devel.x86_64 0:8.4.18-1.el6_4 will be updated
—> Package postgresql-devel.x86_64 0:8.4.20-1.el6_5 will be an update
—> Package postgresql-docs.x86_64 0:8.4.20-1.el6_5 will be installed
—> Package postgresql-jdbc.noarch 0:8.4.701-8.el6 will be installed
–> Processing Dependency: java for package: postgresql-jdbc-8.4.701-8.el6.noarch
—> Package postgresql-libs.x86_64 0:8.4.18-1.el6_4 will be updated
—> Package postgresql-libs.x86_64 0:8.4.20-1.el6_5 will be an update
—> Package postgresql-odbc.x86_64 0:08.04.0200-1.el6 will be installed
—> Package postgresql-plperl.x86_64 0:8.4.20-1.el6_5 will be installed
—> Package postgresql-plpython.x86_64 0:8.4.20-1.el6_5 will be installed
—> Package postgresql-pltcl.x86_64 0:8.4.20-1.el6_5 will be installed
—> Package postgresql-server.x86_64 0:8.4.20-1.el6_5 will be installed
—> Package postgresql-test.x86_64 0:8.4.20-1.el6_5 will be installed
–> Running transaction check
—> Package java-1.7.0-openjdk.x86_64 1:1.7.0.55-2.4.7.1.el6_5 will be installed
—> Package uuid.x86_64 0:1.6.1-10.el6 will be installed
–> Finished Dependency Resolution

Dependencies Resolved

=====================================================================================
Package Arch Version Repository Size
=====================================================================================Installing:
postgresql-contrib x86_64 8.4.20-1.el6_5 updates 354 k
postgresql-docs x86_64 8.4.20-1.el6_5 updates 6.9 M
postgresql-jdbc noarch 8.4.701-8.el6 base 402 k
postgresql-odbc x86_64 08.04.0200-1.el6 base 267 k
postgresql-plperl x86_64 8.4.20-1.el6_5 updates 57 k
postgresql-plpython x86_64 8.4.20-1.el6_5 updates 59 k
postgresql-pltcl x86_64 8.4.20-1.el6_5 updates 46 k
postgresql-server x86_64 8.4.20-1.el6_5 updates 3.4 M
postgresql-test x86_64 8.4.20-1.el6_5 updates 1.1 M
Updating:
postgresql x86_64 8.4.20-1.el6_5 updates 2.6 M
postgresql-devel x86_64 8.4.20-1.el6_5 updates 815 k
postgresql-libs x86_64 8.4.20-1.el6_5 updates 201 k
Installing for dependencies:
java-1.7.0-openjdk x86_64 1:1.7.0.55-2.4.7.1.el6_5 updates 26 M
uuid x86_64 1.6.1-10.el6 base 54 k

Transaction Summary
=====================================================================================
Install 11 Package(s)
Upgrade 3 Package(s)

Total download size: 42 M
Is this ok [y/N]: y
Downloading Packages:
(1/14): java-1.7.0-openjdk-1.7.0.55-2.4.7.1.el6_5.x86_64.rpm | 26 MB 00:29
(2/14): postgresql-8.4.20-1.el6_5.x86_64.rpm | 2.6 MB 00:06
(3/14): postgresql-contrib-8.4.20-1.el6_5.x86_64.rpm | 354 kB 00:00
(4/14): postgresql-devel-8.4.20-1.el6_5.x86_64.rpm | 815 kB 00:01
(5/14): postgresql-docs-8.4.20-1.el6_5.x86_64.rpm | 6.9 MB 00:10
(6/14): postgresql-jdbc-8.4.701-8.el6.noarch.rpm | 402 kB 00:00
(7/14): postgresql-libs-8.4.20-1.el6_5.x86_64.rpm | 201 kB 00:00
(8/14): postgresql-odbc-08.04.0200-1.el6.x86_64.rpm | 267 kB 00:00
(9/14): postgresql-plperl-8.4.20-1.el6_5.x86_64.rpm | 57 kB 00:00
(10/14): postgresql-plpython-8.4.20-1.el6_5.x86_64.rpm | 59 kB 00:00
(11/14): postgresql-pltcl-8.4.20-1.el6_5.x86_64.rpm | 46 kB 00:00
(12/14): postgresql-server-8.4.20-1.el6_5.x86_64.rpm | 3.4 MB 00:03
(13/14): postgresql-test-8.4.20-1.el6_5.x86_64.rpm | 1.1 MB 00:01
(14/14): uuid-1.6.1-10.el6.x86_64.rpm | 54 kB 00:00
————————————————————————————————————————————–
Total 765 kB/s | 42 MB 00:56
Running rpm_check_debug
Running Transaction Test
Transaction Test Succeeded
Running Transaction
Warning: RPMDB altered outside of yum.
Updating : postgresql-libs-8.4.20-1.el6_5.x86_64 1/17
Updating : postgresql-8.4.20-1.el6_5.x86_64 2/17
Installing : postgresql-server-8.4.20-1.el6_5.x86_64 3/17
Installing : uuid-1.6.1-10.el6.x86_64 4/17
Installing : 1:java-1.7.0-openjdk-1.7.0.55-2.4.7.1.el6_5.x86_64 5/17
Installing : postgresql-jdbc-8.4.701-8.el6.noarch 6/17
Installing : postgresql-contrib-8.4.20-1.el6_5.x86_64 7/17
Installing : postgresql-plpython-8.4.20-1.el6_5.x86_64 8/17
Installing : postgresql-pltcl-8.4.20-1.el6_5.x86_64 9/17
Installing : postgresql-test-8.4.20-1.el6_5.x86_64 10/17
Installing : postgresql-plperl-8.4.20-1.el6_5.x86_64 11/17
Installing : postgresql-docs-8.4.20-1.el6_5.x86_64 12/17
Updating : postgresql-devel-8.4.20-1.el6_5.x86_64 13/17
Installing : postgresql-odbc-08.04.0200-1.el6.x86_64 14/17
Cleanup : postgresql-devel-8.4.18-1.el6_4.x86_64 15/17
Cleanup : postgresql-8.4.18-1.el6_4.x86_64 16/17
Cleanup : postgresql-libs-8.4.18-1.el6_4.x86_64 17/17
Verifying : postgresql-jdbc-8.4.701-8.el6.noarch 1/17
Verifying : postgresql-libs-8.4.20-1.el6_5.x86_64 2/17
Verifying : postgresql-plpython-8.4.20-1.el6_5.x86_64 3/17
Verifying : postgresql-contrib-8.4.20-1.el6_5.x86_64 4/17
Verifying : postgresql-server-8.4.20-1.el6_5.x86_64 5/17
Verifying : postgresql-docs-8.4.20-1.el6_5.x86_64 6/17
Verifying : 1:java-1.7.0-openjdk-1.7.0.55-2.4.7.1.el6_5.x86_64 7/17
Verifying : postgresql-devel-8.4.20-1.el6_5.x86_64 8/17
Verifying : postgresql-pltcl-8.4.20-1.el6_5.x86_64 9/17
Verifying : uuid-1.6.1-10.el6.x86_64 10/17
Verifying : postgresql-odbc-08.04.0200-1.el6.x86_64 11/17
Verifying : postgresql-test-8.4.20-1.el6_5.x86_64 12/17
Verifying : postgresql-8.4.20-1.el6_5.x86_64 13/17
Verifying : postgresql-plperl-8.4.20-1.el6_5.x86_64 14/17
Verifying : postgresql-devel-8.4.18-1.el6_4.x86_64 15/17
Verifying : postgresql-libs-8.4.18-1.el6_4.x86_64 16/17
Verifying : postgresql-8.4.18-1.el6_4.x86_64 17/17

Installed:
postgresql-contrib.x86_64 0:8.4.20-1.el6_5 postgresql-docs.x86_64 0:8.4.20-1.el6_5 postgresql-jdbc.noarch 0:8.4.701-8.el6
postgresql-odbc.x86_64 0:08.04.0200-1.el6 postgresql-plperl.x86_64 0:8.4.20-1.el6_5 postgresql-plpython.x86_64 0:8.4.20-1.el6_5
postgresql-pltcl.x86_64 0:8.4.20-1.el6_5 postgresql-server.x86_64 0:8.4.20-1.el6_5 postgresql-test.x86_64 0:8.4.20-1.el6_5

Dependency Installed:
java-1.7.0-openjdk.x86_64 1:1.7.0.55-2.4.7.1.el6_5 uuid.x86_64 0:1.6.1-10.el6

Updated:
postgresql.x86_64 0:8.4.20-1.el6_5 postgresql-devel.x86_64 0:8.4.20-1.el6_5 postgresql-libs.x86_64 0:8.4.20-1.el6_5

Complete!

Start PostgreSQL Service

[root@ jonserver.local opt]# /etc/init.d/postgresql initdb
Initializing database: [ OK ]

Configuration of PostgreSQL

[root@ jonserver.local opt]# vi /var/lib/pgsql/data/pg_hba.conf

# TYPE DATABASE USER CIDR-ADDRESS METHOD

# “local” is for Unix domain socket connections only
local all all trust
# IPv4 local connections:
host all all 127.0.0.1/32 trust

:wq!

Restart PostgreSQL Service

[root@ jonserver.local opt]# /etc/init.d/postgresql restart
Stopping postgresql service: [ OK ] Starting postgresql service: [ OK ]

Create RHQ Database and Users Roles

[root@ jonserver.local opt]# psql postgres postgres
psql (8.4.20)
Type “help” for help.

postgres=# CREATE DATABASE rhq owner=rhqadmin;
CREATE DATABASE
postgres=# CREATE USER rhqadmin with password ‘rhqadmin#@!PKR22’;
CREATE ROLE

Connect Postgresql with rhq Database and rhqadmin User.
postgres=# \c rhq rhqadmin
psql (8.4.20)
You are now connected to database “rhq” as user “rhqadmin”.

rhq=> \q

Great Database Configuration Done

JBOSS Network Operation Installation

[root@ jonserver.local jon]# unzip -q jon-server-3.2.0.GA.zip
[root@ jonserver.local opt]# cd jon-server-3.2.0.GA
[root@ jonserver.local jon-server-3.2.0.GA]# cd bin/
[root@ jonserver.local bin]# ll
total 120
drwxr-xr-x. 2 root root 4096 Dec 12 2013 internal
-rwxr-xr-x. 1 root root 10050 Dec 12 2013 rhqctl
-rw-r–r–. 1 root root 8612 Dec 12 2013 rhqctl.bat
-rw-r–r–. 1 root root 8685 Dec 12 2013 rhq-data-migration.bat
-rwxr-xr-x. 1 root root 9994 Dec 12 2013 rhq-data-migration.sh
-rw-r–r–. 1 root root 119 Dec 12 2013 rhq-encode-password.bat
-rwxr-xr-x. 1 root root 1344 Dec 12 2013 rhq-encode-password.sh
-rw-r–r–. 1 root root 149 Dec 12 2013 rhq-installer.bat
-rwxr-xr-x. 1 root root 152 Dec 12 2013 rhq-installer.sh
-rw-r–r–. 1 root root 149 Dec 12 2013 rhq-server.bat
-rw-r–r–. 1 root root 149 Dec 12 2013 rhq-server-console.bat
-rw-r—–. 1 root root 14900 May 27 11:41 rhq-server.properties
-rwxr-xr-x. 1 root root 152 Dec 12 2013 rhq-server.sh
-rw-r–r–. 1 root root 149 Dec 12 2013 rhq-storage.bat
-rw-r–r–. 1 root root 149 Dec 12 2013 rhq-storage-installer.bat
-rwxr-xr-x. 1 root root 152 Dec 12 2013 rhq-storage-installer.sh
-rw-r–r–. 1 root root 5286 Dec 12 2013 rhq-storage.properties
drwxr-xr-x. 3 root root 4096 Dec 13 2013 wrapper

Enable Chkconfig Postgresql Start Automaticly during Next Boot time

[root@ jonserver.local bin]# chkconfig postgresql on

Configuration of JBoss Network Operation

[root@ jonserver.local bin]# vi rhq-server.properties

# PostgreSQL database Connection Setting!
rhq.server.database.connection-url=jdbc:postgresql:// 192.168.0.200:5432/rhq
rhq.server.database.user-name=rhqadmin
rhq.server.database.password=rhqadmin#@!PKR22
rhq.server.database.type-mapping=PostgreSQL
rhq.server.database.server-name=192.168.0.200
rhq.server.database.port=5432
rhq.server.database.db-name=rhq
hibernate.dialect=org.hibernate.dialect.PostgreSQLDialect
rhq.server.quartz.driverDelegateClass=org.quartz.impl.jdbcjobstore.PostgreSQLDelegate

Please Comment all Oracle DB Connection Strings

# Oracle database
#rhq.server.database.connection-url=jdbc:oracle:thin:@127.0.0.1:1521:xe
#rhq.server.database.user-name=rhqadmin
#rhq.server.database.password=1eeb2f255e832171df8592078de921bc
#rhq.server.database.type-mapping=Oracle10g
#rhq.server.database.server-name=unused
#rhq.server.database.port=unused
#rhq.server.database.db-name=unused
#hibernate.dialect=org.hibernate.dialect.Oracle10gDialect
#rhq.server.quartz.driverDelegateClass=org.quartz.impl.jdbcjobstore.oracle.OracleDelegate

SMTP Setting
# Email settings used to connect to an SMTP server to send alert emails.
rhq.server.email.smtp-host=localhost
rhq.server.email.smtp-port=25
rhq.server.email.from-address=rhqadmin@localhost

#############################################################################
# Host and Port Bindings
# ———————-
# INSTALLATION ACTION REQUIRED! The following property must be explicitly set:
# jboss.bind.address
#
# These define the ports the RHQ Server will bind to. Most of the time
# you can leave these alone. You can change these default values to
# conform to your own environment’s requirements, such as the IP address
# the RHQ Server will bind to (jboss.bind.address) and the ports
# browsers will use to access the RHQ web application
# (rhq.server.socket.binding.port.http, rhq.server.socket.binding.port.https)
# If you change the binding address, you might also want to change
# “rhq.autoinstall.public-endpoint-address” as well.
#############################################################################

# The bind address for the RHQ server (jboss server). To bind the server on
# all network interfaces set to 0.0.0.0, otherwise a specific IP address.
# jboss.bind.address=0.0.0.0
jboss.bind.address=0.0.0.0

# By default only local management connections
jboss.bind.address.management=127.0.0.1

jboss.socket.binding.port-offset=0

jboss.management.native.port=6999
jboss.management.http.port=6990
jboss.management.https.port=6443

rhq.server.socket.binding.port.ajp=7009
rhq.server.socket.binding.port.http=7080
rhq.server.socket.binding.port.https=7443
rhq.server.socket.binding.port.jacorb=2528
rhq.server.socket.binding.port.jacorb-ssl=2529
rhq.server.socket.binding.port.messaging=4449
rhq.server.socket.binding.port.messaging-throughput=4455
rhq.server.socket.binding.port.osgi-http=7090
rhq.server.socket.binding.port.remoting=3447
rhq.server.socket.binding.port.txn-recovery-environment=3712
rhq.server.socket.binding.port.txn-status-manager=3713
#############################################################################
# Installer Settings
# ——————
# INSTALLATION ACTION REQUIRED! Review the default settings:
#
# These enable the installer when starting for the first time.
# To do so, first ensure all values in this properties file are appropriately
# set for your environment. Once you are sure all values are as you want them,
# set rhq.autoinstall.enabled=true and run the server then run the installer.
#
# rhq.autoinstall.enabled: must be true to trigger the automatic install.
# rhq.autoinstall.database: allowed values: auto, overwrite, skip
# “auto” will create a new schema if one does not
# yet exist or, if a schema does exist, will simply
# upgrade it as needed (which keeps existing data).
# “overwrite” if you want to create an empty schema,
# even if one already exists (loses existing data).
# “skip” if you don’t want to do any database
# upgrade or creation. WARNING! You must ensure your
# database schema already exists and is up to date.
# rhq.autoinstall.public-endpoint-address: public IP/hostname that all agents
# will use to talk to this server.
# If not set, a value to use is
# determined at auto-install time.
#############################################################################

rhq.autoinstall.enabled=false
rhq.autoinstall.database=auto

#############################################################################
# Storage cluster configuration settings
#
# IMPORTANT NOTE:
# – Storage Node properties will be stored in the database
# after the initial install. The server will use database stored
# properties during operation and after restarts.
# – Additional servers in an HA topology will use database stored Storage
# Node properties. So properties set in this configuration file will be
# overriden on install with the database values.
#############################################################################

# The username RHQ will use to authenticate against the Storage Cluster.
# The value is generated and should not be edited.
rhq.storage.username=oruhcwbi

:wq!

Start JBoss Nextwork Operation Installation

[root@ jonserver.local bin]# ./rhqctl install

Start JBoss Network Operation Services

[root@ jonserver.local bin]# ./rhqctl start

INFO 13:28:04,160 Node jonserver.local / 192.168.0.200 state
INFO 13:28:04,191 Startup completed! Now serving reads.
Trying to start the RHQ Server…
RHQ Server (pid 5189 ) IS starting
Starting RHQ Agent…
RHQ Agent (pid 5358 ) IS running

Verify JBoss Network Operation Services is UP and Running.
[root@ jonserver.local bin]# ./rhqctl status
13:29:32,208 INFO [org.jboss.modules] JBoss Modules version 1.2.2.Final-redhat-1
RHQ Storage Node (pid 5035 ) IS running
RHQ Server (pid 5189 ) IS running
JBossAS Java VM child process (pid 5189 ) IS running
RHQ Agent (pid 5358 ) IS running
Check and Verify JBoss Network Operation Logs.
[root@ jonserver.local opt]# cd jon/jon-server-3.2.0.GA/logs/
[root@ jonserver.local logs]# tail -f server.log

Great RED HAT JOBSS OPERATION NETWORK Successfully Installed and Verified by Logs

Open Internet Browser, Access GUI Admin Panel

http://192.168.0.200:7080/coregui

Recommended For You.

Setup your own Video sharing website like, Youtube.com , Vimeo.com or dailymotion.com using Clip Bucket video hosting / sharing code
